Peerless DS-VWT955-2X2 Digital Signage 2×2 Video Wall Ceiling Mount

Video wall displays no longer need to be limited to just walls and carts. With the Peerless DS-VWT955-2X2, a video wall display can now be mounted to a ceiling. The tool-less micro adjustable design provides placement of four displays in a 2 x 2 configuration, neatly aligned on the same plane. The tilting adjustment options of 5, 10, 15 and 20 degrees means you can be assured of the perfect viewing angle for your application. Ideal for department stores, entertainment venues or other large public areas. Compatible with Peerless fixed length and adjustable length columns.

Technical Drawing

Features

• Ceiling mounted 2 x 2 video wall solution
• Supports mounting hole patterns of VESA 200 x 200 up to 600 x 400mm. Additional patterns supported with adaptor plates
• Tilts options of 5°, 10°, 15° and 20°
• Eight points of tool-less micro adjustment provide precise alignment
• Compatible with Peerless standard columns
• Included security hardware deters tampering and loss



Technical Specifications

Minimum to Maximum Screen Size	40″ to 55″
Mounting Pattern	Up to 600 x 400
Product Weight	85lb (39kg)
Weight Capacity	400lb (182kg)
Color	Black
Finish	Powder Coat
Security Features	Security Hardware
Interlock Increments	0, +5, +10, +15 degree
Product Dimensions (W x H x D)	71.54″ x 49.0″ x 10.5″ (1817 x 1244 x 267mm)
Shipping Dimensions (L x W x H)	Box 1: 67.4″ x 17.1″ x 4.7″ (1712 x 435 x 119mm) Box 2: 73.5″ x 17.1″ x 4.7″ (1867 x 435 x 119mm)
Shipping Weight	95lb (43kg)
Units in Package	1

Literature (Please open the following documents for more technical information)

Product Sheet – Peerless DS-VWT955-2×2 Digital Signage 2×2 Video Wall Ceiling Mount	– pdf
Installation Instructions – Peerless DS-VWT955-2×2 Digital Signage Video Wall Ceiling Mount	– pdf
