Innovative 9105 Heavy Duty Monitor Arm

24″ of horizontal range

Features
of

innovative 9105-800:

  1.
Heavy-duty steel construction. Extremely durable.

  2.  Monitors
are rendered weightless by the arm

   3.
Rotates 360 degrees at three joints

4.
Monitor tilter mechanism can tilt over 200 degrees

  5.
Integrated cable management system keeps your
work surface free of annoying cable clutter

   6.
Gas cylinder “floats” monitor above desk –
instantly raise and lower monitor

  7.  Optional
upgrade to quick install/release monitor bracket. Consult your
sales rep for details.

  8.  VESA-monitor
compatible – 75mm & 100mm VESA adapters included. Please call
for non-


VESA options

Technical Drawing for

Innovative 9105-1000 Heavy Duty Desk Mount LCD Arm

of Innovative 9105-1500 Desk Mount:

For an exceptionally strong and
durable monitor mount, choose the 9105-FM Heavy Duty LCD Arm.
This steel arm can effortlessly support monitors up to 54
pounds. Includes our spring-assist monitor tilter for effortless
monitor motion.


9105 is ideal for large LCD’s as
well as data-entry applications, where it will support both
monitor and keyboard tray.

Screen Size:

Vertical Range:

Up to 32″

15.5″

Horizontal Range:

24″

Rotation:

360
degrees at three joints

Monitor Tilt:

200
degrees

Monitor Pivot:

Landscape to portrait

Monitor Compatibility:

VESA 75mm and 100mm

Cable Management:

Cables
are clipped beneath arm

Mounting Options:

FLEXmount, Wall, Pole, Thru-Desk

More Images:

Folds to save maximum space

Integrated cable management
