Comparable to our 7000 monitor arm, innovative 7045 mount features a
fixed-position forearm which provides additional vertical reach. The arm
renders the monitor weightless for instant height adjustment. This
flexible monitor arm can be folded out of the way when not in use.
Comparable to model 7000, the 7045 monitor arm features an angled
forearm which provides additional vertical reach for 20″+ monitors.
Technical Drawing
Technical Specifications
| Color | 104 – Vista Black, 124 – Silver, 248 – Flat White |
| Screen Size | Up to 32″ |
| Height Adjustment | 16″ |
| Extension Range | 22″ |
| Pivot | Landscape / Portrait |
| Rotation | 360 degrees at three joints |
| Tilt | 200 degrees |
| VESA Compatibility | 75 & 100mm, adapter included |
| Mount Configurations | Desk Edge, Thru-Desk, Grommet, Wall, Reverse Wall, Side Bolt |
| Warranty | 10 Years |
| Weight Capacity |
|
Features
-
FLEXmount with six mounting options is available
-
Arm mount features 16″ of vertical range and 22″ of horizontal
range -
Flexible monitor arm folds to occupy just 3″ of space
-
Monitor tilter mechanism can tilt over 200 degrees
-
Arm rotates 360 degrees at three joints
-
VESA-monitor compatible – 75mm & 100mm VESA adapters included;
please call for non-VESA options -
Optional upgrade to quick install/release monitor bracket;
consult your sales rep for details -
Optional 6″ extender tube available to raise monitor (see
Extender Tubes under Available Accessories)
| Model | 7045 |
| Manufacturer | Innovative LCD Arms |
| Part Number | 7045 |
| Tilt | 200 degree |
| Mounting Options | Desk |
| Mounting Options | Wall |
| Mounting Options | Pole |
| Mounting Options | Slatwall |
| Monitor Arm Types | 1 Monitor |
| Number of Monitors | 1 Monitor |
| Monitor Size | Up to 32 |
| Color | 104 – Vista Black, 124 – Silver and 248 – Flat White |
| Height Adjustment | 16 |
| Extension | 22 |
| Pivot | Landscape/Portrait |
| Rotation | At three joints 360 degree |
| Mounting Options | Desk Edge, Thru-Desk, Grommet, Wall, Reverse Wall, Side Bolt |
| Mounting Pattern | VESA 75mm and 100mm |
| Warranty | 10 Years |
| Weight Capacity | 7045-500: 7.5 – 15 lbs (3.4 – 6.8 kg), 7045-800: 10 – 22 lbs (4.5 – 10.0 kg), 7045-1000: 12.5 – 29.5 lbs (5.7 – 13.4 kg) |
| Price | $200 – $299 |
