Innovative 7000-T Flexible Height Adjustable Laptop Arm

Innovative 7000-T combines our best-selling 7000 Arm with our award-winning laptop bracket. Create an instant height-adjustable docking station for your laptop! You’ll save valuable desk space and work in greater ergonomic comfort. The 7000 radial arm enables you to quickly reposition the laptop with just one hand. FLEXmount, with 6 mounting options including desktop and grommet clamp, thru-desk bolt, and wall mounting are available.



Please
note this monitor arm was updated in January 2022. The manufacturer, Innovative Design Works, has upgraded two separate parts.

Tilter – A tilter is the part
of the adjustable monitor arm that attaches to the back of your monitor
and allows the monitor to rotate, pivot and tilt to desired
position.  This monitor arm is now available with Next Gen Tilter
8500. This new tilter apart from being slim and sleek has a quick release
bracket, which makes installation and release easy and fast. It has a 30
lb weight capacity. However please bear in mind that the Next Gen Tilter
8500 comes with 100mm VESA adapter unlike the earlier standard tilter
which comes with 75mm and 100mm adapter plate. If your monitor has only
75x75mm VESA pattern, please contact us through monitor arm finder. We will find the best monitor arm that matches your
needs.

8500 Quick Release Monitor Tilter

8336 Standard Monitor Tilter

Mount – Mount is the part
that attaches the monitor arm to the desk or wall. The new mount, is called Top Down mount,
Innovative 8524. It functions as a clamp or grommet mount for desk
installation and allows you to install the arm from above the desk without
having to crawl underneath the desk. The FLEXmount, shown below, offers 6 mounting options including desk edge, wall mount, thru-desk, side bolt, grommet and reverse wall mount. Please see Mounting Options.


8524 Top Down Mount




Technical Drawing



Technical Specifications

Horizontal Range:	24″ (61 cm)
Vertical Range:	16″ (8″ up and down from horizontal)
Rotation:	360° at three joints
Monitor Tilt:	200°
Cable Management:	Cables routed underneath arm
Mounting Options:	FLEXmount, Slatwall, Wall, Thru-Desk
Monitor Weight:	3 – 15 lbs (1.4 – 6.8 kg)



Features

• Adjustable laptop bracket accommodates laptops of any size
• 24″ of horizontal range
• 16″ of vertical range (8″ up and down from horizontal)
• Folds up to occupy just 3″ of space
• Rotates 360 degrees at three joints
• Monitor tilter mechanism can tilt over 200 degrees
• Optional 6″ extender tube available to raise monitor (see Extender Tubes under Available Accessories)
• Mounting arm floats computer above desk – simply grab and move to desired position
• Securely grips laptop with quick attach and release
• Adjustable clasps allow free access to jacks and ports
• When used with tablet PCs, enables one-handed use of the tablet
• Integrated cable management keeps cords off the desk
