Add ergonomic adjustability and portability while saving space with
this unique all-in-one stand. Ergotron 33-338-085 includes a Secure
Clamp (SC), adjustable CPU holder. The perfect accessory for
space-constrained areas, it enables you to mount both a CPU and display
while providing effortless height adjustment of the monitor.
Technical Drawing
Technical Specifications
| Screen | Capacity | Lift | Tilt | Pan | Rotation | VESA |
| Up to 24″ | 6 – 16 lbs 2.7 – 7.3 kg | 5″ 12.7 cm | 30° | 360° | 360° | MIS-D |
Product Information
| Part Number | 33-338-085 |
| Neo-Flex All-In-One SC Lift Stand with Secure Clamp CPU Holder (black) | |
| Includes |
|
| Not Included | CPU, keyboard and monitor not included |
| Weight Capacity | 6–16 lbs (2.7–7.2 kg) for display; total stand capacity = 37 lbs (16.7 kg) for combined weight of display, CPU, keyboard and mouse |
| Motion | Motion may be restricted when using 22″–24″ monitors in portrait mode |
| Mounting Standards | VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm) |
| Height Adjustment | Five-inch (13 cm) height adjustment ergonomically accommodates average range of users |
| Meets | Tip test requirements of UL Specification 1678 |
| Portrait to Landscape Rotation | Removal of lock screw allows portrait to landscape rotation |
| Compatible | Compatible with most 15″–24″ displays, and most small or ultra small form factor CPUs |
| CPU Size | Maximum CPU size = 14″H x 4.5″D (35.6 x 11.4 cm); minimum CPU size = 7″H x 2″D (17.8 x 5.1 cm). Provided rubber spacer must be used to accommodate CPU depths of less than 3″ (7.6 cm). The CPU should be centered on the stand |
| Mounting Option | Two M4 threaded screw inserts are located at the bottom of the base to allow for attachment of the stand to worksurface. Screws not supplied. Hole-spacing from center to center = 4.5″ (11.4 cm) |
| Product Weight | 6.6 lbs (3 kg) |
| Shipping Dimensions | 24″ x 20″ x 8″ (61 x 51 x 20 cm) |
| Shipping Weight | 10 lbs (4.5 kg) |
| Warranty | Three (3) years |
Benefits
-
Transport a workstation anywhere easily and quickly
-
Deploy multiple complete computer systems with ease; pick up
systems using the integrated handle and lock them up at night -
Mix and match CPU box and monitor from different vendors;
update the display or CPU without disturbing full system -
Includes a Secure Clamp (SC), adjustable CPU holder; deters
theft and keeps CPU firmly in place -
Position your display for maximum ergonomic comfort to
relieve eye, neck and back strain -
Compact design and small footprint keeps workspace manageable
– great for computer labs -
Easy to use – simple installation and effortless operation
-
Patented Constant Force lift-and-pivot motion technology
| Model | 33-338-085 |
| Manufacturer | Ergotron |
| Part Number | 33-338-085 |
| UPC | 698833010954 |
| Weight | lb(s) |
| Color | Black |
| Monitor Size | Up to 24″ |
| Weight Capacity | 6–16 lbs (2.7–7.2 kg) for display; total stand capacity = 37 lbs (16.7 kg) for combined weight of display, CPU, keyboard and mouse. |
| Lift | (12.7 cm) 5 in |
| Tilt | 30 degree |
| Pan | 360 degree |
| Rotation | 360 degree |
| Mounting Pattern | VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm & 75 x 75 mm) |
| CPU Dimension | Maximum CPU size = 14″H x 4.5″D (35.6 x 11.4 cm); minimum CPU size = 7″H x 1.3″D (17.8 x 3.3 cm). Provided rubber spacer must be used to accommodate CPU depths of less than 3″ (7.6 cm). The CPU should be centered on the stand |
| Shipping Dimensions | 24″ x 20″ x 8″ (61 x 51 x 20 cm) |
| Shipping Weight | 10 lbs (4.5 kg) |
| Warranty | Three (3) years |
| Mounting Options | Desk Stand |
| Weight | 6.6 lbs (3 kg) |
