Chief K1C220 enhanced Kontour K1C Dynamic Height-Adjustable Column
Mounts are the perfect solutions for the office, healthcare facilities
or home. K1C mounts provide the maximum amount of both dynamic and
manual height adjustment for the ultimate ergonomic solution. And
best-in-class weight capacity range makes specification simple.
Key enhancements have been made to Chief’s patented Centris Extreme Tilt
technology for effortless fingertip monitor positioning. Kontour monitor
mounts float your displays in the optimal ergonomic position above your
work surface to create a more productive and comfortable work
environment.
Technical Drawing
Specifications
| Color | Black, Silver and White |
| Certifications | TAA Compliant |
| Desktop Thickness Range | 0.50 – 2.50″ (12.7 – 63.5 mm) |
| Dynamic Height Adjustment | 13″ (330.2 mm) |
| Manual Height Adjustment | 7.0″ (177.8 mm) |
| Maximum Extension | 20.6″ (523 mm) |
| Minimum Depth | 2.45″ (62 mm) |
| Mounting Pattern Compatibility (Universal Versions) | 75 x 75mm, 100 x 100mm |
| Notes | Weight capacity is per monitor |
| Number of Monitors | 2 |
| Screen Array Configuration | 2 x 1 |
| Shipping Weight | 18.7 lbs (8.48 kg) |
| Tilt | +75°, -10° |
| Typical Screen Sizes | 10 – 30″ (254 – 762 mm) diagonals |
| Weight Capacity | 5 – 25 lbs (2.3 – 11.3 kg) |
| Orientation | Landscape, Portrait |
Features
-
Best-in-class weight capacity range of 5 to 25 lbs makes
specification simple -
No need to pay more for that “heavy duty” arm to support your
Apple monitor or All-in-One -
Sleek, solidly-constructed forged aluminum arms in subtle
silver & black finishes -
Enhanced patented Centris Extreme Tilt provides +75°, -10° of
effortless tilt, for optimal viewing comfort whether sitting or
standing -
Enhanced column interface enables easy upgrades from single- to
dual- or triple-monitor installations without impacting the existing
installation, future-proofing your investment -
20″ (508 mm) of total height adjustment range
-
13″ (330 mm) of dynamic height adjustment using smooth motion
gas-spring technology -
Additional 7″ (178 mm) of manual height adjustment on the
column -
Enhanced 3-step installation and quick-release monitor
interface for easy mounting and maintenance, with included tool
storage in the updated base -
Easily clamps to edge of desk, through standard grommet hole,
or through bolt hole with included kit -
Tool-free cable management covers for a clean, professional
look -
With high levels of recycled content & a highly-recyclable
design, Chief Kontour monitor arms may contribute to valuable LEED-CI,
-NC, and -EB credits -
Most Kontour K1 products are TAA-compliant – see respective
product pages for details
| Model | K1C220B, K1C220S, K1C220W |
| Manufacturer | Chief Mounts |
| Part Number | K1C220B, K1C220S, K1C220W |
| UPC | 841872160085 |
| Color | Black, Silver and White |
| Desktop Thickness Range | 0.50 – 2.50 |
| Dynamic Height Adjustment | 13 |
| Manual Height Adjustment | 7.0 |
| Maximum Extension | 20.6 |
| Minimum Depth | 2.45 |
| Mounting Pattern | 75 x 75mm, 100 x 100mm |
| Shipping Weight | 18.7 lbs (8.48 kg) |
| Tilt | +75 degree, -10 degree |
| Monitor Size | 10 – 30 |
| Weight Capacity | 5 – 25 lbs (2.3 – 11.3 kg) |
| Orientation | Landscape, Portrait |
| Mounting Options | Desk |
| Monitor Arm Types | 2 Monitors |
| Number of Monitors | 2 Monitors |
| Maximum Monitor Size | 30 |
| Monitor Placement | Side-by-Side |
